Description
This Extra Heavy-Duty top-of-the-line high R-value door is constructed using 20-Gauge exterior steel that is foamed-in-place with polyurethane insulation which creates a strong monolithic panel that is energy efficient.
Maximum R-value
Our polyurethane insulation provides the best R-Values per inch when compared to other common types of sectional door insulation.
Security + Strength
20-gauge steel exterior skin with the added strength of foamed-in-place polyurethane insulation provide maximum strength and security for your opening
Section Profile
Flush Stucco
Construction
Steel + Insulation + Steel
Track: All Amarr Doors are available with both
2″ or 3″ track in Standard Lift, High Lift, Vertical Lift,
Low Headroom, and Follow the Roof Pitch. Custom track configurations are also available. For drawings and more information, please visit our downloads website.
Hardware: Amarr hardware includes minimum
14-gauge galvanized steel hinges and 13-gauge galvanized steel track brackets. All rollers have
minimum 10-ball bearings.
Springs: Torsion springs are oil tempered, helical wound and custom computed for each door for a minimum 10,000 cycle life. Optional springs are available up to 100,000 cycle life.
Windows
 24″x12″ Insulated |  26” x 13” insulated |
 24″ x 6″ Insulated |  Full View |
Colors
Commercial White
Specifications
| R-VALUE | 19.4 |
|---|---|
| STEEL THICKNESS | 20/27 Ga. |
| PANEL DESIGN | Flush |
| STEEL EMBOSSMENT | Stucco |
| CONSTRUCTION LAYERS | Three |
| MAX STD WIDTH | 40’2″ |
| MAX STD HEIGHT | 26’1″ |
| DOOR THICKNESS | 2″ (5.1cm) |
