Description
Amarr’s Model 2731 features two steel skins surrounding 1 3/8″ inches of CFC-free polystyrene. Each skin consists of wood grain-embossed flush 27-gauge steel to provide a solid wall of protection from the elements.
STRENGTH + INSULATION
27 gauge exterior and interior steel bonds to rigid polystyrene to create a strong, energy efficient panel.
ECO-FRIENDLY
Amarr’s polystyrene insulation is free of Ozone depleting Chlorofluorocarbons (CFC) while providing efficient insulation to help reduce the negative environmental impact of heating and cooling energy use.
Section Profile
Flush Wood-grain Embossed
Construction
Triple Layer Steel + Insulation + Steel
Windows
 21″ x 13″ Short Panel |  24″ x 6″ Double Insulated Acrylic |
 41″ x 13″ Long Panel |
Colors
- True White
- Almond
- Sandtone
- Wicker Tan
Specifications
| R-VALUE | 6.7 |
|---|---|
| STEEL THICKNESS | 27/27 Ga. |
| PANEL DESIGN | Flush |
| STEEL EMBOSSMENT | Woodgrain |
| CONSTRUCTION LAYERS | Three |
| MAX STD WIDTH | 18’2″ |
| MAX STD HEIGHT | 14’1″ |
| DOOR THICKNESS | 1 3/8″(3.5cm) |
